Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in manufacturing construction equipment. They make machines like manlifts, boom lifts and aerial lifts. These machines are designed to facilitate access to areas which are difficult to reach, large equipment, buildings and roofs, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also known as OSHA refers to a power-driven endless belt. This belt moves just in one direction and includes platforms, or steps or handholds which are attached to the unit to be able to move personnel from each floor.
TB85
The TB85 by Terex provides a maximum working height of 91 feet. In addition, the maximum height of the platform reaches 85 feet. This model's maximum width is 8 feet, 1 and 1/2 inches. The TB85 has dimensions measuring 9 inches wide and 9 feet, 1-inch high by 36 feet. This particular model offers a reach of 70 feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is roughly 9 feet high by 8.5 feet wide by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, while the max working height reaches 116 feet. The model is 9 feet, 4 inches high x 8 feet wide when stowed away. The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
