The tower crane's base is typically bolted to a huge concrete pad which provides really crucial support. The base is attached to a tower or a mast and stabilizes the crane which is attached to the inside of the structure of the building. Usually, this attachment point is to an elevator shaft or to a concrete lift.
The crane's mast is often a triangulated lattice structure which measures 0.9m2 or 10 feet square. Attached to the very top of the mast is the slewing unit. The slewing unit consists of a motor and a gear which allows the crane to rotate.
Tower cranes are able to have a maximum unsupported height of 80m or 265 feet. The tower crane's maximum lifting capacity is 16,642 kg or 39,690 pounds with counter weights of 20 tons. In addition, two limit switches are used to be able to make sure that the operator does not overload the crane. There is even another safety feature called a load moment switch to ensure that the operator does not surpass the ton meter load rating. Last of all, the maximum reach of a tower crane is 70 meters or 230 feet.
Due to their extreme heights, there is a science involved to erecting a crane. The stationary structure will at first need to be transported to the construction site by utilizing a large tractor-trailer rig setup. Then, a mobile crane is utilized so as to assemble the machinery portion of the jib and the crane. Then, these parts are attached to the mast. Afterward, the mobile crane adds counterweights. Forklifts and crawler cranes may be some of the other industrial machinery that is commonly used to erect a crane.
Mast extensions are added to the crane as the building is erected. This is how the height of the crane could match the building's height. The crane crew utilizes what is known as a climbing frame or a top climber which fits between the slewing unit and the top of the mast. A weight is hung on the jib by the work crew so as to balance the counterweight. When complete, the slewing unit is able to detach from the top of the mast. In the top climber, hydraulic rams are utilized to adjust the slewing unit up an extra 6.1m or 20 feet. Then, the crane operator utilizes the crane to insert and bolt into place another mast part piece.
