Jib Crane Types
Jib cranes are made up of a trolley hoist on a horizontal load-bearing boom. This boom is connected to a pivoting vertical member and up to 20 feet long. Jib cranes could move loads between any areas within the boom's arc of rotation. Light duty units are utilized within warehouses and factories for loads weighing up to 5 tons. The web site BestJibCranes.com features the major kinds of jib cranes as being either free-standing, wall-mounted or mast mounted.
Free Standing
Free-standing jib cranes could stand alone not needing support from the building structure. The horizontal boom in this particular situation is attached to a pivoting vertical column that is solidly anchored to the floor of the building. This kind of jib crane needs a foundation made of either concrete or steel and could rotate a full 360 degrees.
Mast-Type
The vertical column on the mast-type jib cranes are supported by pivot points at the top and the bottom. These pivots are connected to the floor of the building and the overhead steel structure. These jib-cranes provide 360 degrees of rotation with the advantage of not needing the massive foundation required for free-standing units.
Wall Mounted
The wall-mounted jib cranes provide a horizontal boom which is attached to the wall of a building rather than the normal vertical column. These machinery are great in places where the full 360 degree rotation is not needed and offer up to 200 degrees of rotation.
There are two model varieties, depending on how the boom is supported. One of the kinds uses a tie rod which is connected from above the wall to the boom. The other type supports the boom from below by utilizing a cantilever brace which is attached to the wall also.
